PP, PE, ABS, PS, HDPE, PP broken crushed material double two stage recycling and granulation line machine

Raw material and advantages:

The production line is the ideal equipment of plastic granulation, especially for PP, PE, ABS, PS sheet, HDPE, PP solid broken material recycling and granulation. The production line has the advantages of novel design, reasonable structure, stable operation, low noise, low energy consumption and high yield etc.. Vacuum exhaust or natural exhaust port design can exclude the waste gas and discharging water in the production process, which can be more stable in extrusion, more dense particles, and guarantee the good quality of the product.

Capacity: 100-1000KG/H

Product Detail

Product Tags

Main parameter

Screw loader

● It matches with extruder feeding hopper to realize automatic control.

Screw loader


● Hopper material: Stainless steel; Feeding method: Screw feeding; Feeder controller: Controlled by inverter.

Extruder machine

● Single screw extruder with Efficient air exhausting to improve the material quality.It equipped with a special design of the barrel and screw and single screw exhaust system, can ensure high yield.

Extruder machine
Vacuum air exhausting system

Vacuum air exhausting system

● Efficient air exhausting to improve the material quality.
● Exhausting style: vacuum water filter.
● Vacuum room: special design.
● Vacuum cover plate: aluminum alloy.
● Vacuum tube: temperature and pressure resistance rubber tubes.

Single stage granulation and double stage granulation are determined by the material. Below are the detailed information of the second stage extruder.

Baby extruder

● Two-stage extruder can more effectively discharge water and impurities from materials, and the quality of particles is better.

Baby extruder
Screen changer

Screen changer

● Different screen changers meet the needs of different customers.

We mainly have three modes of pellets cutting system:
1. The water ring cutting system.
2. The strand cutting system.
3. The underwater strand cutting system.
Based on different material characteristics, we will recommend different cutting methods.

1. Water ring cutting system

● The cutting system adopts extrusion die head water ring to cut, which can ensure the perfect appearance of particle.

Centrifugal dewatering machine

Centrifugal dewatering machine

● This machine have many advantages, such as high degree of dehydration, low power consumption, high efficiency, high degree of automation, and greatly reduces labor intensity. Dehydration is clean, and it is also can wash off the micro sand and small sundries in the pla.

2. Strand cutting system

● For some materials with high viscosity, such as PP, we recommend using a strip cutting method.

3.Underwater stand cutting system

3. Underwater stand cutting system

● Suitable for high melting materials, such as PET and PP and so on.

● Air pipeline drying

The water in pellets surface is evaporated through air pipeline conveying principle, and it transports the dried pellets to the collection hopper, then for follow-up treatment.

Air pipeline drying
Vacuum air exhausting system1

Electrical control system

● PLC automatic control

Material diagram

Vacuum air exhausting system2
Vacuum air exhausting system3
Vacuum air exhausting system4
Vacuum air exhausting system34
