PP/PE film & bags recycling compactor granulation line

This production line is an ideal equipment which used for recycling waste plastic film, bit, sheet( below 0.5mm), belt, bag and so on. It has novel design, compact structure and reasonable layout, stable movement and convenient maintenance. Meanwhile, Low noise and consumption is also its advantage.

Capacity: 150-1500KG/H

Product Detail

Product Tags

Main parameter

Conveyor+ metal detector
● It matches with compactor to realize automatic control.
● Metal detector is on the middle of the belt, to detect the metal from the materials, customized China brand or German brand.

bags single stage recycling granulation line4
bags single stage recycling granulation line5

Compactor machine

● This machine adopts the imported technology, using grinding rapidly, continuous mixing, the mixing friction heating, rapid cooling and contraction principle, cause the plastic film, sheet, strip, wire, a soft plastic tube, foam materials, degradable materials and granular from waste material into reproduction, which is the latest model of plastic recycling ideal granulating equipment.

Film roll feeding device

● If the film is in a roll shape, this feeding device can be installed to achieve online film feeding function, saving labor. Customized

bags single stage recycling granulation line6
bags single stage recycling granulation line7

Side feeding device

● If you have some crushed materials that need to be mixed with film materials to form pellets, we can add a feeder device to the compactor barrel body. Customized.

Extruder machine

● Single screw extruder with Efficient air exhausting to improve the material quality. It equipped with a special design of the barrel and screw and single screw exhaust system, can ensure high yield.

bags single stage recycling granulation line8
bags single stage recycling granulation line9

Vacuum air exhausting system
● Efficient air exhausting to improve the material quality.
● Exhausting style: vacuum water filter.
● Vacuum room: special design.
● Vacuum cover plate: aluminum alloy.
● Vacuum tube: temperature and pressure resistance rubber tubes.

Single stage granulation and double stage granulation are determined by the material. Below are the detailed information of the second stage extruder.

Baby extruder

● Two-stage extruder can more effectively discharge water and impurities from materials, and the quality of particles is better.

Baby extruder
Screen changer

Screen changer

● Different screen changers meet the needs of different customers.

We mainly have three modes of pellets cutting system:
1. The water ring cutting system.
2. The strand cutting system.
3. The underwater strand cutting system.
Based on different material characteristics, we will recommend different cutting methods.

1. Water ring cutting system

● The cutting system adopts extrusion die head water ring to cut, which can ensure the perfect appearance of particle.

Centrifugal dewatering machine

Centrifugal dewatering machine

● This machine have many advantages, such as high degree of dehydration, low power consumption, high efficiency, high degree of automation, and greatly reduces labor intensity. Dehydration is clean, and it is also can wash off the micro sand and small sundries in the pla.

2. Strand cutting system

● For some materials with high viscosity, such as PP, we recommend using a strip cutting method.

3.Underwater stand cutting system

3. Underwater stand cutting system

● Suitable for high melting materials, such as PET and PP and so on.

● Air pipeline drying

The water in pellets surface is evaporated through air pipeline conveying principle, and it transports the dried pellets to the collection hopper, then for follow-up treatment.

Air pipeline drying
Electrical control system

Electrical control system

● PLC automatic control

Material diagram

Material diagram1
Material diagram2
Material diagram3
Material diagram4
